Product Description

The ‘Swarg Systems & Instruments’ test rig comprises of air cooled petrol engine provided with rope brake dynamometer. Rope brake is water cooled. Temperatures are measured by a digital temperature indicator. Various measurements provided enable to determine B. H. P., fuel and air intake and brake thermal efficiency, at various loads.

SPECIFICATIONS
1) Engine – 150 cc. Horizontal cylinder, air cooled petrol engine developing 3 kw at 6000 rpm.
2) Rope brake – 260 mm. Coupled to engine, with rope wound around the drum. Spring balance for loading the engine. Water cooling arrangement for the brake drum OR Electrical Dynamometer can be also supplied with water rheostat
3) Air Intake Measurement – Intake tank of 250 250 250 mm. Fitted with orifice and water manometer.
4) Fuel Intake Measurement – Calibrated burette with there way cock assembly for cutting off the fuel supply from the tank.
5) Exhaust Gas Calorimeter – Water cooled exhaust gas calorimeter , shell and coil type to study the heat lost to exhaust gases.
6) Multichannel digital temperature indicator for measuring inlet and outlet temperatures of exhaust gases and water.
A detailed technical manual accompanies the unit.

SERVICES REQUIRED
1) Foundation as per our drawing.
2) 230 V, 50Hz, AC supply.
3) Water supply of about 10 lit/min.
4) Tachometer, 0-9999 rpm, contact type.
